For model AA1400 Detector Amplifier brown; dial knobs black, RCA (RCA Victor Co. Inc.); New York (NY):
upper knob missing skirt.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1923 Category: Radio module pre 1926 (not a part, not a key)
Valves / Tubes 3: UV200 UV201 UV201
Main principle Detector with Vacuum Tube (Valve), no tuner; 2 AF stage(s); Reaction
Wave bands - without
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: AA1400 Detector Amplifier [brown; dial knobs black] - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 11 x 9 x 5.75 inch / 279 x 229 x 146 mm
Notes Made for RCA by General Electric. In conjunction with the regenerative tuner AR1300 the AA1400 on a wooden base and top made up the Radiola V, a regenerative receiver.
Painted faux mahogany metal case with bakelite knobs with black metal skirts.
Price in first year of sale 75.00 $
Mentioned in Radio Manufacturers of the 1920's, Vol. 3 (pp.21,25)
Literature/Schematics (4) Radiola, the golden Age of RCA

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
