Alhambra II (2)

Alhambra II ; RCA RCA Victor Co. (ID = 844379) Radio

Alhambra II ; RCA RCA Victor Co. (ID = 1046147) Radio

Alhambra II ; RCA RCA Victor Co. (ID = 1046148) Radio

Alhambra II ; RCA RCA Victor Co. (ID = 1046149) Radio
Alhambra II ; RCA RCA Victor Co. (ID = 365901) Radio
Use red slider bar for more.
Alhambra II ; RCA RCA Victor Co. (ID = 365901) Radio
RCA RCA Victor Co.: Alhambra II [Radio] ID = 365901 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Alhambra II (2), RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1925/1926 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UX199 UX199 UX199 UX199 UX199 UX120
Main principle Superhet with RF-stage
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries
Loudspeaker Magnetic loudspeaker (reed) generic.
Power out
from Radiomuseum.org Model: Alhambra II - RCA RCA Victor Co. Inc.; New
Material Wooden case
Dimensions (WHD) 35 x 33 x 25 inch / 889 x 838 x 635 mm
Notes Also Victor 7-2, and Radiola 25.
Price in first year of sale 425.00 $
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Circuit diagram reference Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
Mentioned in Radio Manufacturers of the 1920's, Vol. 3
