AA1400 Detector Amplifier green; silver dials

AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 1027703) mod-pre26

AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 1027704) mod-pre26

AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 1027705) mod-pre26

AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 1027706) mod-pre26

AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 1027707) mod-pre26
AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 888431) mod-pre26 AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 888432) mod-pre26
AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 639768) mod-pre26 AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 1243347) mod-pre26
Use red slider bar for more.
AA1400 Detector Amplifier; RCA RCA Victor Co. (ID = 888431) mod-pre26
RCA RCA Victor Co.: AA1400 Detector Amplifier [mod-pre26] ID = 888431 933x830
Select picture or schematic to display from thumbnails on the right and click for download.
For model AA1400 Detector Amplifier green; silver dials, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1922 Category: Radio module pre 1926 (not a part, not a key)
Valves / Tubes 3: UV200 UV201 UV201
Main principle Detector with Vacuum Tube (Valve), no tuner; 2 AF stage(s); Reaction
Wave bands - without
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: AA1400 Detector Amplifier [green; silver dials] - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Tablemodel, with any shape - general.
Notes
Made for RCA by General Electric. In conjunction with the AR1300 regenerative tuner , the AA1400 made up a regenerative receiver. This combination, painted green and with silver plated dials, was replaced by 1923 by the Radiola V Model AR-885 which appeared nearly identical except painted with a woodgrained finish and with a wood top cover to be more aesthetically pleasing.
Net weight (2.2 lb = 1 kg) 34 lb (34 lb 0 oz) / 15.436 kg
Price in first year of sale 75.00 $
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Mentioned in Radio Manufacturers of the 1920's, Vol. 3
Literature/Schematics (1) Radio Broadcast, June 1922, page 169
Literature/Schematics (2) RCA catalog 1922 "Radio Enters the Home"
Literature/Schematics (3) Radiola, the golden Age of RCA
