Amplifier MI-13297

Amplifier MI-13297; RCA RCA Victor Co. (ID = 1983987) Ampl/Mixer Amplifier MI-13297; RCA RCA Victor Co. (ID = 1983988) Ampl/Mixer
Amplifier MI-13297; RCA RCA Victor Co. (ID = 1987684) Ampl/Mixer Amplifier MI-13297; RCA RCA Victor Co. (ID = 1987685) Ampl/Mixer
Amplifier MI-13297; RCA RCA Victor Co. (ID = 1987689) Ampl/Mixer Amplifier MI-13297; RCA RCA Victor Co. (ID = 1987691) Ampl/Mixer
Amplifier MI-13297; RCA RCA Victor Co. (ID = 1987693) Ampl/Mixer
Use red slider bar for more.
Amplifier MI-13297; RCA RCA Victor Co. (ID = 1983987) Ampl/Mixer
RCA RCA Victor Co.: Amplifier MI-13297 [Ampl/Mixer] ID = 1983987 1400x928
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amplifier MI-13297, RCA (RCA Victor Co. Inc.); New York (NY):
aus ebay, #231814298317, Verkäufer antique_audio

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1950 ?? Category: Audio Amplifier or -mixer
Valves / Tubes 9: 6J7 6J7 6J7 6SC7 6SF5 6SL7GT 6L6G 6L6G 5U4G
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (unknown quality)
from Radiomuseum.org Model: Amplifier MI-13297 - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Tablemodel, low profile (big size).
Notes

PA amplifier; inputs: 3x Microphone + Phonograph.

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
