For model AR-60T, AR-60S table versions, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1936–1938 Category: Commercial Receiver (may include amateur bands)
Valves / Tubes 10: 6D6 6D6 6C6 6D6 6D6 6B7 6F7 41 6C6 84 991
Main principle Superhet, double/triple conversion
Wave bands Short Wave (SW only)
Details
Power type and voltage AC/DC-set / 110; 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: AR-60T, AR-60S [table versions] - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 22.25 x 12.5 x 17.875 inch / 565 x 318 x 454 mm
Notes

Coverage 1.5 to 25 Mc. Hinged top cover, Tone Control, AVC on/off, Audio filter, BFO, RF gain, Bandspread, Crystal filter. 10 tubes plus neon stabilizer for the LO.

- AR-60T: black or gray wrinkle frinish. price $485.
- AR-60S: DeLuxe version of AR-60T in two-tone gray finish, sitting on a wooden base.
Price $495.

There are also the rack mount versions AR-60R and AR-60G,
and the U.S.Coast guard versions  CGR-32-1 and CGR-32-2.

Mentioned in Shortwave Receivers - Past & Present (3rd ed.) (p.452)
Literature/Schematics (1) Short Wave Craft January 1936 page 534.
