RCA RCA Victor Co.: AR-77E [Commercial Re] ID = 2293194 1400x731
Select picture or schematic to display from thumbnails on the right and click for download.
For model AR-77E revised, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1948 ?? Category: Commercial Receiver (may include amateur bands)
Valves / Tubes 9: 6SK7 6K8 6SK7 6SK7 6H6 6SJ7 6SQ7 6F6G 5Y3G VR150-30
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: AR-77E [revised] - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Tablemodel, with any shape - general.
Notes Export model. Choice of AC and DC Power Packs.
Frequency coverage: 540 to 31,000 kc in 6 bands.
Circuit diagram reference Rider's Perpetual, Volume 15 = 1947 and before
