O-50 Portable Victrola
Use red slider bar for more.
RCA RCA Victor Co.: O-50 Portable Victrola [R-Player] ID = 1089184 477x818
Select picture or schematic to display from thumbnails on the right and click for download.
For model O-50 Portable Victrola, RCA (RCA Victor Co. Inc.); New York (NY):
Data taken from RCA Service Notes
|
|
alternative name
|
RCA Manufacturing || Victor Talking Machine
|
Year:
1939
|
Category: Sound/Video Recorder and/or Player |
Valves / Tubes |
3:
6SF5 6F6G 5Y3G
|
Wave bands |
- without |
Details |
Rec.Player+Audio.Amp+LS |
Power type and voltage |
Alternating Current supply (AC) / 105-125 Volt |
Loudspeaker |
Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm |
Power out |
|
from Radiomuseum.org |
Model: O-50 Portable Victrola - RCA RCA Victor Co. Inc.; New |
Material |
Leather / canvas / plastic - over other material |
Shape |
Tablemodel, with any shape - general. |
Dimensions (WHD) |
15 x 8.75 x 16.875 inch / 381 x 222 x 429 mm |
Notes |
Mains operated "portable" Phonograph (for 78´s) |
Net weight (2.2 lb = 1 kg) |
26 lb (26 lb 0 oz) / 11.804 kg |
Price in first year of sale |
49.95 USD |
Source of data |
Beitman Radio Diagrams, Vol. 02, 1939 |
Circuit diagram reference |
Beitman Radio Diagrams Vol. 2, 1939 |
Literature/Schematics (1) |
RCA Victor Service Notes "Red Book" Series |
Model page created by Walter Wiesmüller † May 2012. See "Data change" for further contributors.
All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
Here you find 4928 models, 2898 with images and 4002 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
