PM18 Ch= RS-179 Ch= RS-177A

RCA (RCA Victor Co. Inc.); New York (NY)

  • Year
  • 1959 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 151122
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 9
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Rec.Player+Audio.Amp+LS
  • Power type and voltage
  • Alternating Current supply (AC) / 110 - 120 Volt
  • Loudspeaker
  • 7 or more Loudspeakers
  • from Radiomuseum.org
  • Model: PM18 Ch= RS-179 Ch= RS-177A - RCA RCA Victor Co. Inc.; New
  • Notes
  • AC operated stereo preamplifier, stereo amplifier and 4 speed automatic record changer. Sams photofact set 491 folder 12 date 7-60 features the RCA models PM17 and PM18 with preamp chassis RS-179 and amp chassis RS-177A, the models TPM11 and TPM12 with tuner chassis RC-1192, preamp chassis RS-179 and amp chassis RS-177A as the same schematic.
  • Author
  • Model page created by Peter Hoddow. See "Data change" for further contributors.
