• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1932 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 195419

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: Portable Turntable PT-33 - RCA RCA Victor Co. Inc.; New

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 18.25 x 9.125 x 13.5 inch / 464 x 232 x 343 mm

• Notes
• The PT-33 is a portable two speed turntable which is to be used with a radio receiver.

• Net weight (2.2 lb = 1 kg)
• 25 lb (25 lb 0 oz) / 11.350 kg

• Source of data
• RCA Victor Service Notes "Red Book" Series

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
