Q10 Ch=RC594C early

Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 1110216) Radio

Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 1110217) Radio

Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 1110218) Radio

Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 211397) Radio

Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 211398) Radio

Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 211399) Radio

Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 211400) Radio
Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 466525) Radio
Use red slider bar for more.
Q10 Ch=RC594C; RCA RCA Victor Co. (ID = 466525) Radio
RCA RCA Victor Co.: Q10 Ch=RC594C [Radio] ID = 466525 793x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Q10 Ch=RC594C early, RCA (RCA Victor Co. Inc.); New York (NY):
Knobs are not original.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1946 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 1.25 W (unknown quality)
from Radiomuseum.org Model: Q10 Ch=RC594C [early] - RCA RCA Victor Co. Inc.; New
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 10.25 x 6.75 x 6 inch / 260 x 171 x 152 mm
Notes There is a Model Q-10A too. Operates from DC or 40-100 Hz AC.
Net weight (2.2 lb = 1 kg) 6.25 lb (6 lb 4 oz) / 2.838 kg
External source of data Sammlung de Tolve
Circuit diagram reference Rider's Perpetual, Volume 15 = 1947 and before
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series (RCA Victor Service Data 1943-1946, Page 5)

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
