Q10A Ch= RC-594C early

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 1110223) Radio

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 1110224) Radio

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 1110225) Radio

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 19771) Radio

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 211404) Radio

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 211405) Radio

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 211406) Radio

Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 211407) Radio
Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 2355) Radio
Use red slider bar for more.
Q10A Ch= RC-594C; RCA RCA Victor Co. (ID = 2355) Radio
RCA RCA Victor Co.: Q10A Ch= RC-594C [Radio] ID = 2355 679x525
Select picture or schematic to display from thumbnails on the right and click for download.
For model Q10A Ch= RC-594C early, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1946 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6G 35Z5G
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 210-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out 1.25 W (unknown quality)
from Radiomuseum.org Model: Q10A Ch= RC-594C [early] - RCA RCA Victor Co. Inc.; New
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 250 x 170 x 150 mm / 9.8 x 6.7 x 5.9 inch
Notes Export version. Price in Switzerland 275 SFR. Operates from DC or 40-100Hz AC.
Net weight (2.2 lb = 1 kg) 6.25 lb (6 lb 4 oz) / 2.838 kg
External source of data E. Erb 3-907007-36-0
Circuit diagram reference Rider's Perpetual, Volume 15 = 1947 and before
Mentioned in Die «Thali Schemasammlung» führt das Modell
Literature/Schematics (2) RCA Victor Service Notes "Red Book" Series (RCA Victor Service Data 1943-1946, Page 5)
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
