RCA RCA Victor Co.: Q122 Ch= RC601 [Radio] ID = 401751 412x315
Select picture or schematic to display from thumbnails on the right and click for download.
For model Q122 Ch= RC601, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1948 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6SA7 6SG7 6SQ7 6AT6 6F6G 6F6G 5Y3GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 105-125; 200-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6.5 inch = 16.5 cm
Power out 4.2 W (unknown quality)
from Radiomuseum.org Model: Q122 Ch= RC601 - RCA RCA Victor Co. Inc.; New
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 16.5 x 10.5 x 6.5 inch / 419 x 267 x 165 mm
Notes Frequency Ranges:
BC band - 535 to 1620 kc
SW1 - 2.4 to 6.4 mc
SW2 - 9.3 to 12.15 mc
SW3 - 14.85 to 16.1 mc
SW4 - 21.0 to 27.0 mc
External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
Literature/Schematics (1) Rider's Perpetual, Volume 17 = covering 1947
Literature/Schematics (2) RCA Victor Service Notes "Red Book" Series
