R-93 3rd run Phono white
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1935 ?
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 54602
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: R-93 3rd run Phono [white] - RCA RCA Victor Co. Inc.; New
- Dimensions (WHD)
- 11 x 5 x 8 inch / 279 x 127 x 203 mm
- Notes
- magnetic pickup.
- Net weight (2.2 lb = 1 kg)
- 8.5 lb (8 lb 8 oz) / 3.859 kg
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 8 = 1937 and before
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
