Radiola 16 AR-924

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 50709) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 124336) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1671251) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1028639) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1028640) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1028641) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1028642) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1028643) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1028644) Radio

Radiola 16 AR-924; RCA RCA Victor Co. (ID = 1028645) Radio
Radiola 16 AR-924; RCA RCA Victor Co. (ID = 309278) Radio Radiola 16 AR-924; RCA RCA Victor Co. (ID = 309279) Radio
Radiola 16 AR-924; RCA RCA Victor Co. (ID = 309281) Radio Radiola 16 AR-924; RCA RCA Victor Co. (ID = 267218) Radio
Radiola 16 AR-924; RCA RCA Victor Co. (ID = 309280) Radio Radiola 16 AR-924; RCA RCA Victor Co. (ID = 309282) Radio
Radiola 16 AR-924; RCA RCA Victor Co. (ID = 733687) Radio Radiola 16 AR-924; RCA RCA Victor Co. (ID = 733689) Radio
Radiola 16 AR-924; RCA RCA Victor Co. (ID = 908080) Radio Radiola 16 AR-924; RCA RCA Victor Co. (ID = 908083) Radio
Use red slider bar for more.
Radiola 16 AR-924; RCA RCA Victor Co. (ID = 309278) Radio
RCA RCA Victor Co.: Radiola 16 AR-924 [Radio] ID = 309278 607x373
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiola 16 AR-924, RCA (RCA Victor Co. Inc.); New York (NY):
Ebay Nr. 150104795261 Bild bearbeitet.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1927 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UX201A UX201A UX201A UX201A UX201A UX112A
Main principle TRF without regeneration
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Radiola 16 AR-924 - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 16.5 x 8.25 x 7.5 inch / 419 x 210 x 191 mm
Notes

The RCA Radiola 16 is a battery operated 6 tube BC band receiver.

The tuning capacitor design is similar to the design used in the Radiola 18 AC receiver.  These tuners are frequently found to be frozen.  The precedure to repair this can be found here: Tuning-Capacitor-Fix

Schematic, pictures and service notes listed in detail in the RCA Victor Service Notes for 1923-1928 (RCA Redbook 1923-1928).

Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 1 = 1931/1934 (for 1919-1931)
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) RCA Victor Service Notes for 1923-1928 (RCA Redbook)
