Radiola 33 DC Console (220 V)
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1929
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 196116
-
- alternative name: RCA Manufacturing || Victor Talking Machine
- - Manufacturers Literature /
- - Manufacturers Literature /
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- TRF with regeneration
- Tuned circuits
- 3 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Direct Current supply (DC) / 200-240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- from Radiomuseum.org
- Model: Radiola 33 DC [Console ] - RCA RCA Victor Co. Inc.; New
- Shape
- Console, Highboy (legs > 50 %).
- Dimensions (WHD)
- 8.75 x 31 x 27 inch / 222 x 787 x 686 mm
- Notes
- RCA Radiola 33 DC, Console (220V);
- Net weight (2.2 lb = 1 kg)
- 42 lb (42 lb 0 oz) / 19.068 kg
- Source of data
- - - Manufacturers Literature
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
- Author
- Model page created by a member from A. See "Data change" for further contributors.
