Radiola 80 4 knobs (with tone control)

• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1930/1931

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 245870

• • alternative name: RCA Manufacturing || Victor Talking Machine

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 9

• Valves / Tubes
• UY224 UY227 UY224 UY224 UY224 UY227 UX245 UX245 UX280

• Main principle
• Superhet with RF-stage; ZF/IF 175 kHz; something special ? Please give information (notes)

• Tuned circuits
• 10 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Power out
• 3 W (undistorted)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiola 80 [4 knobs ] - RCA RCA Victor Co. Inc.; New

• Shape
• Console, Lowboy (legs < 50 %).

• Notes

• Controls (by 4 knobs):
  Volume,
  Tone control,
  Tuning,
  Switch local / distance





• Mentioned in
• Radiola, the golden Age of RCA

• Literature/Schematics (1)
• Pre-War Consoles

• Author
• Model page created by Paul Kasindorf. See "Data change" for further contributors.
