2X62 Ch= RC-1080D
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- alternative name: RCA Manufacturing || Victor Talking Machine
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- Main principle
- Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 115 Volt
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Power out
- 0.85 W (unknown quality)
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 2X62 Ch= RC-1080D - RCA RCA Victor Co. Inc.; New
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 11.8 x 8.6 x 7.5 inch / 300 x 218 x 191 mm
- The RCA 2X62 is an AC/DC operated 6 tube AM receiver. AM Band Tuning Range: 540 - 1600kHz. Cabinet color is Ivory. Uses Qty(1) PM 4" speaker. Has built-in loop antenna. Uses Qty(2) #1490 bayonet dial lamps wired in series.
- Net weight (2.2 lb = 1 kg)
- 3.6 kg / 7 lb 14.9 oz (7.93 lb)
- External source of data
- Ernst Erb
- Source of data
- The Radio Collector's Directory and Price Guide 1921 - 1965
- Circuit diagram reference
- Beitman Radio Diagrams Vol. 13, 1953
- Mentioned in
- Machine Age to Jet Age II (page 232.)
- Literature/Schematics (1)
- Rider's Perpetual, Volume 23 (last) = covering up to 1954
- Literature/Schematics (2)
- RCA Victor Service Notes "Red Book" Series (Volume VIII 1952, Page 41)
- Other Models
Here you find 5086 models, 3197 with images and 4110 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
Forum contributions about this model: RCA RCA Victor Co.: 2X62 Ch= RC-1080D
Threads: 1 | Posts: 16
Hello, I've been working on a rca 6-62 and ran into a snag that I can't figure out. Both the IF and RF 5th pin (cathode) voltage is high 1.8 V DC. I believe because of this, I can't pick up stations but the radio does have white noise. Any ideas? Very greatful for your help.
Bill Boles, 28.Jun.16
