For model V-205 Ch= RC-521, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 9: 6SK7 6SA7 6SK7 6H6 6SF5 6SF5 6F6G 6F6G 5U4G
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Short Wave(s) and Police.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 105-125 Volts, 25, 50 or 60 Hz. Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 12 W (unknown quality)
from Radiomuseum.org Model: V-205 Ch= RC-521 - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 35 x 35.94 x 17.13 inch / 889 x 913 x 435 mm
Notes The RCA "1941 Victrola Line" was announced in "The Music Trade Review" (August 1940 Issue), and consisted of: Four "Anniversary" models (e.g., V-205 & V-405); Three "DeLuxe" models (e.g., V-302 & V-300); four "Master" models (e.g., V-170, V-200 & V-201); and, two table models. The V-205 Model has the following frequency ranges: Band A = 540-1,600 kHz, Band B = 1,550-4,000 kHz, and Band C = 5,800-18,000 kHz. Automatic Tuning Frequency Range: 540-1,550 kHz.
The V-205 console was produced with one of six Record Players (RP-152, RP-152-A, RP-152-B, RP-152-C, RP-152-D, and RP-152-J).
Power Output is clarified in specifications as 10 Watts Undistorted and 12 Watts Maximum.
Net weight (2.2 lb = 1 kg) 102 lb 0 oz (102 lb) / 46.308 kg
Price in first year of sale 150.00 $
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 12 = ca. 1941 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) RCA Victor Technical Information and Service Data, 1940, Number 34, First Printing.
Literature/Schematics (2) Radio Retailing (Radio & Television R.) (February 1941.)
Literature/Schematics (3) RCA Victor Service Notes "Red Book" Series
