Select picture or schematic to display from thumbnails on the right and click for download.
For model U121 Ch= RC-348J, RCA (RCA Victor Co. Inc.); New York (NY):
Image Courtesy of Mark V. Stein for Radiomuseum.org use only.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6A8G 6K7 6H6 6F5 6K6G 5Y3G
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 2 W (unknown quality)
from Radiomuseum.org Model: U121 Ch= RC-348J - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 25.75 x 34 x 16.75 inch / 654 x 864 x 425 mm
Notes This model has 5 power supply ratings:
Rating A6...105-125V, 60 Cycles
Rating A5...105-125V, 50 Cycles
Rating B2...105-125V, 25 Cycles
Rating C6...105-125;210-250V, 60 Cycles
Rating C5...105-125;210-250V, 50 Cycles
Net weight (2.2 lb = 1 kg) 55 lb (55 lb 0 oz) / 24.970 kg
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 10 = 1939 and before
Mentioned in Guide to Old Radios
Literature/Schematics (1) Beitman Radio Diagrams, Vol. 02, 1939
Literature/Schematics (2) RCA Victor Service Notes "Red Book" Series
Literature/Schematics (3) Pre-War Consoles
