T63 Ch= RC-472F

T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 980363) Radio

T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 980364) Radio

T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 980366) Radio

T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 980367) Radio

T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 174177) Radio

T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 922745) Radio

T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 922749) Radio
T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 281795) Radio T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 174174) Radio
Use red slider bar for more.
T63 Ch= RC-472F; RCA RCA Victor Co. (ID = 281795) Radio
RCA RCA Victor Co.: T63 Ch= RC-472F [Radio] ID = 281795 933x514
Select picture or schematic to display from thumbnails on the right and click for download.
For model T63 Ch= RC-472F, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6SA7 6K7 6SQ7 6F6G 6U5 5Y3G
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: T63 Ch= RC-472F - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 19 x 10.3 x 8.5 inch / 483 x 262 x 216 mm
Notes Pilot lamp: Mazda Nº 51, 6.3 V, 0.20 amp. This model has 3 power supply ratings:
Rating A...105-125V, 50-60 Cycles
Rating B...105-125V, 25-60 Cycles
Rating C...105-130;140-160;200-250V, 40-60 Cycles
Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 11 = ca. 1940 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) RCA Victor Instruments Service Notes 1939
Literature/Schematics (2) Machine Age to Jet Age II (page 245.)
