U40 Ch= RC-498A

U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 981009) Radio

U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 981010) Radio

U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 981011) Radio

U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 981012) Radio

U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 981013) Radio

U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 60190) Radio
U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 712659) Radio U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 1744342) Radio
Use red slider bar for more.
U40 Ch= RC-498A; RCA RCA Victor Co. (ID = 712659) Radio
RCA RCA Victor Co.: U40 Ch= RC-498A [Radio] ID = 712659 600x691
Select picture or schematic to display from thumbnails on the right and click for download.
For model U40 Ch= RC-498A, RCA (RCA Victor Co. Inc.); New York (NY):
Image Courtesy of Mark V. Stein for Radiomuseum.org use only.

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6SA7 6K7 6SQ7 6SF5 6F6G 6F6G 5Y3G
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 5 W (unknown quality)
from Radiomuseum.org Model: U40 Ch= RC-498A - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 30 x 33 x 16.25 inch / 762 x 838 x 413 mm
Notes This model has 5 power supply ratings:
Rating A6...105-125V, 60 Cycles
Rating A5...105-125V, 50 Cycles
Rating B2...105-125V, 25 Cycles
Rating C6...105-130;140-160;200-250V, 60 Cycles
Rating C5...105-130;140-160;200-250V, 50 Cycles
Net weight (2.2 lb = 1 kg) 90 lb (90 lb 0 oz) / 40.860 kg
Price in first year of sale 119.95 USD
External source of data Ernst Erb
Source of data Guide to Old Radios
Circuit diagram reference Rider's Perpetual, Volume 11 = ca. 1940 and before
Mentioned in Pre-War Consoles
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series
