For model RCA-Rider Chanalyst 162 50-60 Hz, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Service- or Lab Equipment
Valves / Tubes 12: 76 1852 6E5 6E5 6E5 6E5 6H6 6K7 6K7 6Q7 6SK7 6X5G
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: RCA-Rider Chanalyst 162 [50-60 Hz] - RCA RCA Victor Co. Inc.; New
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 16 x 9 x 10.75 inch / 406 x 229 x 273 mm
Notes John F.Rider designed this all purpose instrument for systematic diagnosis in radio repair. It has 5 indicators: besides a DC voltmeter it uses four magic eyes for the "channels" RF/IF, AF, Watts, and Oscillator. Two separate tunable sections for RF/IF and Oscillator tests.

The RF/IF channel covers 3 bands: 95 - 260 kc; 240 - 630 kc; 600 - 1700 kc.

The Oscillator channel has a tuned amplifier covering 3 bands: 600 - 1700 kc; 1650 - 4950 kc; 4800 - 15000 kc. Coverage of Oscillator operation extends up to 70 megacycles.

The name is combined from "channel" and "analyst" = "Chanalyst". The tube complement is somewhat different from the initial publication, where 4 x 6K7 were foreseen. They remained in the RF/IF section, while the other two 6K7 were replaced by an 1852 and a 6SK7 respectively.

Power requirements: Model 162 is 105-125 Volts, 50-60 Hertz, 60 Watts; Model 162A is 105-125 Volts, 25-50 Hertz, 60 Watts.
You can find a Chanalyst model comparison here.
Net weight (2.2 lb = 1 kg) 28 lb 0 oz (28 lb) / 12.712 kg
Price in first year of sale 107.00 $
Source of data - - Manufacturers Literature
Literature/Schematics (1) - - Manufacturers Literature (1939 RCA Victor Service Notes, First Edition)

Model page created by Mark Wm. Manis. See "Data change" for further contributors.



All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
Here you find 4951 models, 2913 with images and 4015 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
RCA RCA Victor Co.: RCA-Rider Chanalyst 162
Threads: 2 | Posts: 2
Hits: 114     Replies: 0
rca: RCA-Rider Chanalyst 162C -- stand-by function
Rich Post
09.Jun.21
  1

One of the important changes made in the RCA-Rider Chanalyst 162C was adding a stand-by function to the power switch.  That served to preserve the life of the 6E5 indicator tubes by cutting off most B+ to the tubes except for a feed by way of a 100K ohm resistor.  Most earlier models have much of the upper green image on the tubes worn out except for the lower portion which is activated only by the four channels. I will upload a copy of the 162-C, code 643 schematic which shows the stand-by function.


Hits: 2456     Replies: 0
rca: 162; RCA-Rider Chanalyst
Konrad Birkner † 12.08.2014
14.Dec.10
  1

There is a comprehensive comparison spreadsheet describing the particularities of the Rider Chanalyst Models, prepared by Mark Manis.

A, AX, 11, 11A, 162, 162A, 162B, 162C, and TS-303/AG.

Thank You, Mark.
