612V4 Ch= RK-121 RS-123
RCA (RCA Victor Co. Inc.); New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1947
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 53607
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Data taken from RCA datasheet
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 12
- Main principle
- Superhet with RF-stage; ZF/IF 455/10700 kHz
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 612V4 Ch= RK-121 RS-123 - RCA RCA Victor Co. Inc.; New
- Shape
- Console with Push Buttons.
- Notes
- Radio chassis RK-121, Amp.chassis RS-123.
Uses record changer RP176.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 18 = 1949 and before
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
- Literature/Schematics (4)
- Riders 17,18 ,20
