- Country
- United States of America (USA)
- Manufacturer / Brand
- RCA (RCA Victor Co. Inc.); New York (NY)
- Year
- 1948
- Category
- Sound/Video Recorder and/or Player
- Radiomuseum.org ID
- 54754
-
- alternative name: RCA Manufacturing || Victor Talking Machine
Sams Photofact Set 44 Folder 27 - 08 - 1948
Click on the schematic thumbnail to request the schematic as a free document.
- Wave bands
- - without
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: RP-177 - RCA RCA Victor Co. Inc.; New
- Shape
- Chassis only or for «building in»
- Notes
- Automatic record changer, 78rpm, crystal pickup cartridge w.sapphire point. For up to twelve 10-inch or ten 12-inch records, not intermixed.
- External source of data
- Ernst Erb
- Circuit diagram reference
- Rider's Perpetual, Volume 18 = 1949 and before
- Mentioned in
- Photofact Folder, Howard W. SAMS (Vol.5 8/48 4814-27 Set 44 Folder 27)
- Literature/Schematics (1)
- RCA Victor Service Notes "Red Book" Series
