For model T-55 Ch= RC-418, RCA (RCA Victor Co. Inc.); New York (NY):
frontview

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6SA7 6SK7 6SQ7 6F6G 5Y3G
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
Power out 2 W (unknown quality)
from Radiomuseum.org Model: T-55 Ch= RC-418 - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 15.625 x 9.5 x 7 inch / 397 x 241 x 178 mm
Notes This model has 3 power supply ratings:
Rating A...105-125V, 50-60 Cycles
Rating B...105-125V, 25-60 Cycles
Rating C...105-125;200-250V, 50-60 Cycles
Net weight (2.2 lb = 1 kg) 12.5 lb (12 lb 8 oz) / 5.675 kg
Price in first year of sale 27.95 USD
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 11 = ca. 1940 and before
Mentioned in Guide to Old Radios
Literature/Schematics (1) Beitman Radio Diagrams, Vol. 02, 1939
Literature/Schematics (2) RCA Victor Service Notes "Red Book" Series
Literature/Schematics (3) Machine Age to Jet Age II (page 245.)
