T-121 Ch= KCS34C

RCA (RCA Victor Co. Inc.); New York (NY)

Data
Forum
Pictures
Collections

  • Year
  • 1950/1951
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 131726
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 24
  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2.6 W (max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: T-121 Ch= KCS34C - RCA RCA Victor Co. Inc.; New
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 22 x 18 x 21.25 inch / 559 x 457 x 540 mm
  • Notes

  • The RCA T-121 is a 12" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with picture tube 12LP4. Cabinet color is Mahogany. Uses Qty(1) elliptical PM 5" x 7" speaker. Has phono input jack to permit use of external record player.

    The schematic and chassis of this model is also used in RCA model T-120.

  • Net weight (2.2 lb = 1 kg)
  • 92 lb (92 lb 0 oz) / 41.768 kg
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
