TC-125 Ch= KCS34C

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386899) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386900) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386901) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386902) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386904) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386905) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386906) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386907) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386908) Television

TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1386909) Television
TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1375194) Television
Use red slider bar for more.
TC-125 Ch= KCS34C; RCA RCA Victor Co. (ID = 1375194) Television
RCA RCA Victor Co.: TC-125 Ch= KCS34C [Television] ID = 1375194 933x1370
Select picture or schematic to display from thumbnails on the right and click for download.
For model TC-125 Ch= KCS34C, RCA (RCA Victor Co. Inc.); New York (NY):
Picture from RCA databook

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1950/1951 perfect model Category: Television Receiver (TV) or Monitor
Valves / Tubes 24: 6AG5 6AG5 6J6 6AU6 6AU6 6AL5 6AV6 6K6GT 6BA6 6AG5 6BA6 6AG5 6AL5 12AU7 6SN7GT 6SN7GT 6SN7GT 6K6GT 6SN7GT 6BG6G 6W4GT 1B3GT 5U4G 12LP4
Main principle Superhet with RF-stage
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC) / 60 cycles, 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
Power out 2.6 W (max.)
from Radiomuseum.org Model: TC-125 Ch= KCS34C - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 25.25 x 36.25 x 21.25 inch / 641 x 921 x 540 mm
Notes

The RCA TC-125 is a 12" b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with picture tube 12LP4. Cabinet color is Walnut, Mahogany or Oak.  Has phono input jack to permit use of external record player.

The schematic and chassis used in models TC-124, TC-125 and TC-126 is also used in RCA models T-120 and T-121 except for the addition of a jewel lamp.  For service data and schematic, refer to service data for models T-120 and T-121.  The speaker used in models TC-124, TC-125 and TC-126 is a 12" PM type instead of the elliptical PM 5" x 7" type used in models T-120 and T-121.

Net weight (2.2 lb = 1 kg) 100 lb (100 lb 0 oz) / 45.4 kg
Source of data -- Collector info (Sammler)
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series (RCA Victor Service Data Volume VI 1950 Pages 221-222, 193-220)
Literature/Schematics (2) Photofact Folder, Howard W. SAMS (Set 93 Folder 9 Date 5-50)

Model page created by a member from A. See "Data change" for further contributors.
