• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1936

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 194130

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6C6 6C6 6A7 6F7 80

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 110-120 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Test Oscillator 150A - RCA RCA Victor Co. Inc.; New

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 13.75 x 9.25 x 7.5 inch / 349 x 235 x 191 mm

• Notes
• This model is similar to model 150 except that this model operates with 25-40 Cycle AC input power.

• Net weight (2.2 lb = 1 kg)
• 17 lb (17 lb 0 oz) / 7.718 kg

• Source of data
• RCA Victor Service Notes "Red Book" Series

• Author
• Model page created by John Kusching. See "Data change" for further contributors.
