• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1935

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 95853

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• 30 30

• Wave bands
• - without

• Power type and voltage
• Storage and/or dry batteries / 4.5 & 22.5 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Signal Generator TMV-97-C - RCA RCA Victor Co. Inc.; New

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 9.75 x 6.5 x 4.5 inch / 248 x 165 x 114 mm

• Notes
• All-Wave Test Oscillator.

• Price in first year of sale
• 35.00 $

• Literature/Schematics (1)
• 1938 Radolek Catalog

• Literature/Schematics (2)
• RCA Victor Service Notes "Red Book" Series

• Author
• Model page created by Vitor Oliveira. See "Data change" for further contributors.
