RCA RCA Victor Co.: U9 Ch= RC-482B [Radio] ID = 1089187 654x720
Select picture or schematic to display from thumbnails on the right and click for download.
For model U9 Ch= RC-482B, RCA (RCA Victor Co. Inc.); New York (NY):
Data taken from RCA Service Notes

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12SA7 12SK7 12SQ7 50L6GT 35Z5GT
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 1.3 W (unknown quality)
from Radiomuseum.org Model: U9 Ch= RC-482B - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 17.5 x 10.375 x 13.375 inch / 445 x 264 x 340 mm
Notes This model has 2 power supply ratings:
Rating A6...105-125V, 60 Cycles
Rating A5...105-125V, 50 Cycles
Net weight (2.2 lb = 1 kg) 9.988 lb (9 lb 15.8 oz) / 4.535 kg
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 11 = ca. 1940 and before
Mentioned in Guide to Old Radios
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series


All listed radios etc. from RCA (RCA Victor Co. Inc.); New York (NY)
