• Year
  • 1956
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 99127
    • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Alternating Current supply (AC) / 105-125 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Oscilloscope WO-91A - RCA RCA Victor Co. Inc.; New
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 9 x 13.5 x 16.5 inch / 229 x 343 x 419 mm
  • Notes
  • 5" oscilloscope, dual-band response; wide band position flat -1 db from 10 cps to 4.5 mc.
  • Price in first year of sale
  • 230.00 $
  • Literature/Schematics (1)
  • Allied Radio Catalog Nº 150, 1956
  • Author
  • Model page created by Vitor Oliveira. See "Data change" for further contributors.
