GM 10 Transistor MT-1102 (Japan 709)
Realtone Electronics Corp.; New York
- Country
- United States of America (USA)
- Manufacturer / Brand
- Realtone Electronics Corp.; New York
- Year
- 1965 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 306508
-
- alternative name: Realtone, NY
- Number of Transistors
- 10
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 4 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Dry Batteries / PP3: 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.6 inch = 6.6 cm
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: GM 10 Transistor MT-1102 - Realtone Electronics Corp.;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 5.5 x 3.2 x 1.5 inch / 140 x 81 x 38 mm
- Notes
-
Similar to the models reported under Showa.
Most of them have the same badge: king with crown on shield.
Weight includes 9V battery.
Made in Japan 709
- Net weight (2.2 lb = 1 kg)
- 0.66 lb (0 lb 10.6 oz) / 0.300 kg
- Author
- Model page created by Aldo Andreani. See "Data change" for further contributors.
