Rondine "La Sinfonica"

Rondine 'La Sinfonica'; Reca Marke (ID = 582331) Radio Rondine 'La Sinfonica'; Reca Marke (ID = 582323) Radio
Rondine 'La Sinfonica'; Reca Marke (ID = 582325) Radio Rondine 'La Sinfonica'; Reca Marke (ID = 582324) Radio
Rondine 'La Sinfonica'; Reca Marke (ID = 582327) Radio Rondine 'La Sinfonica'; Reca Marke (ID = 582328) Radio
Rondine 'La Sinfonica'; Reca Marke (ID = 582329) Radio Rondine 'La Sinfonica'; Reca Marke (ID = 582330) Radio
Use red slider bar for more.
Rondine 'La Sinfonica'; Reca Marke (ID = 582331) Radio
Reca Marke: Rondine "La Sinfonica" [Radio] ID = 582331 933x604
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rondine 'La Sinfonica', Reca (Marke)

Country:  Germany
Manufacturer / Brand:  Reca (Marke)
Year: 1960 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH81 UF89 UBC81 UL84 UY85
Main principle Superheterodyne (common)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out 2 W (unknown quality)
from Radiomuseum.org Model: Rondine "La Sinfonica" - Reca Marke
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 260 x 150 x 110 mm / 10.2 x 5.9 x 4.3 inch
Notes Deutsche Skala.
Net weight (2.2 lb = 1 kg) 1.9 kg / 4 lb 3 oz (4.185 lb)

Model page created by Peter Roggenhofer † 25.4.18. See "Data change" for further contributors.



All listed radios etc. from Reca (Marke)
Here you find 1 models, 1 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
