B9225

B9225; REMA, Fabrik für (ID = 1974173) Speaker-P

B9225; REMA, Fabrik für (ID = 1974174) Speaker-P
B9225; REMA, Fabrik für (ID = 190825) Speaker-P B9225; REMA, Fabrik für (ID = 1974172) Speaker-P
Use red slider bar for more.
B9225; REMA, Fabrik für (ID = 190825) Speaker-P
REMA, Fabrik für: B9225 [Speaker-P] ID = 190825 400x300
Select picture or schematic to display from thumbnails on the right and click for download.
For model B9225, REMA, Fabrik für Rundfunk, Elektrotechnik und Mechanik, Stollberg (Ostd.)

Country:  Germany
Manufacturer / Brand:  REMA, Fabrik für Rundfunk, Elektrotechnik und Mechanik, Stollberg (Ostd.)
Year: 1980 ? Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 2 Loudspeakers
Power out 25 W (unknown quality)
from Radiomuseum.org Model: B9225 - REMA, Fabrik für Rundfunk,
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 230 x 360 x 210 mm / 9.1 x 14.2 x 8.3 inch
Notes 2-Wege-Kompaktbox. Volumen: 10 l; Nennbelastbarkeit: 25 W an 4 Ω, Weichentrennfrequenz 3,6 kHz, Übertragungsbereich 60...16.000 Hz. Lautsprecherbestückung L2911 und L5914.
Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Source of data -- Original prospect or advert
Mentioned in radio fernsehen elektronik 1981, H.11

Model page created by Wolfgang Lill. See "Data change" for further contributors.
