• Country
• Germany

• Manufacturer / Brand
• REMA, Fabrik für Rundfunk, Elektrotechnik und Mechanik, Stollberg (Ostd.)

• Year
• 1983

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 75132

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 35

• Semiconductors
• КТ349 КТ209Б КТ3126А КТ817 A277D A290D SF235 SF127 SF117 SC236 SC237 SC239 SC307 SC308 SC309 SD336 GA101 GA113 KA213 SY360 SZX21 VQA18 VQA28

• Main principle
• Superheterodyne (common); ZF/IF 10,7MHz/ 455kHz

• Tuned circuits
• 7 AM circuit(s)     13 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Various materials

• from Radiomuseum.org
• Model: Marcato RX40 - REMA, Fabrik für Rundfunk,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 450 x 130 x 295 mm / 17.7 x 5.1 x 11.6 inch

• Notes

• ICs: 2; LEDs: 7
  Ausgangsleistung: 2× 15 W (Sinus).
  Baugleich mit RX20, jedoch erhöhte NF-Ausgangsleistung.

  eingebaute Ferritantenne schaltbar

• External source of data
• RFE 12/83

• Source of data
• Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Jörg Kulbe. See "Data change" for further contributors.
