Grid-Dip Meter MR-1

Grid-Dip Meter MR-1; Retex S.A.; (ID = 923412) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1536743) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928347) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928348) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928349) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928350) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928351) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928352) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928353) Equipment

Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928354) Equipment
Grid-Dip Meter MR-1; Retex S.A.; (ID = 918345) Equipment Grid-Dip Meter MR-1; Retex S.A.; (ID = 1928344) Equipment
Use red slider bar for more.
Grid-Dip Meter MR-1; Retex S.A.; (ID = 918345) Equipment
Retex S.A.;: Grid-Dip Meter MR-1 [Equipment] ID = 918345 581x645
Select picture or schematic to display from thumbnails on the right and click for download.
For model Grid-Dip Meter MR-1, Retex S.A.; Hospitalet de LLobregat

Country:  Spain
Manufacturer / Brand:  Retex S.A.; Hospitalet de LLobregat
Year: 1960 Category: Service- or Lab Equipment
Valves / Tubes 1: 6T4 or 6AF4
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 125 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Grid-Dip Meter MR-1 - Retex S.A.; Hospitalet de
Material Metal case
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 65 x 180 x 80 mm / 2.6 x 7.1 x 3.1 inch
Notes

Gama de frecuencias: 1,6 a 200 mHz en 5 escalas.

El kit modelo MR-2 consiste en un juego de bobinas cubriendo de 400 kHz a 1.600 kHz.

El kit modelo MR-3 es un modulador para el MR-1.

El precio incluye un manual. Se podía comprar cualquier manual suelto por 100 pts.

Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Price in first year of sale 1'495.00 ESP
Source of data - - Manufacturers Literature
Literature/Schematics (4) Catálogo RetexKit 1960

Model page created by Alberto Sanna-Alonso. See "Data change" for further contributors.
