Sextetta ML
Rex-Plastic, Max Ernst KG.; Nürnberg
- Country
- Germany
- Manufacturer / Brand
- Rex-Plastic, Max Ernst KG.; Nürnberg
- Year
- 1960 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 217598
- Number of Transistors
- 6
- Main principle
- Superheterodyne (common); 2 AF stage(s)
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Dry Batteries / 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Sextetta [ML] - Rex-Plastic, Max Ernst KG.;
- Shape
- Very small Portable or Pocket-Set (Handheld) < 8 inch.
- Dimensions (WHD)
- 170 x 90 x 45 mm / 6.7 x 3.5 x 1.8 inch
- Notes
- Es gibt Geräte mit verschiedenen Transistor-Bestückungen. Beispiele: 1. OC400, 2x GFT45/15, GFT22/15, 2x GFT21/15A 2. OC400, 2x OC390, GFT21, 2x GFT21/15
- Price in first year of sale
- 99.50 DM
- Mentioned in
- Funkschau (FS) 1960 / 7 Seite 155 Listung in Tabelle "Die neuen Transistorempfänger"
- Author
- Model page created by Hans-Jürgen Neuhaus. See "Data change" for further contributors.
