Masterpiece Radiogram
Reynolds Universal Manufacturing Co., Ltd.; Birmingham
- Country
- Great Britain (UK)
- Manufacturer / Brand
- Reynolds Universal Manufacturing Co., Ltd.; Birmingham
- Year
- 1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 352545
- Number of Tubes
- 10
- Valves / Tubes
- Main principle
- Superhet with RF-stage
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 220-240 Volt
- Loudspeaker
- Presumably Dynamic Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Masterpiece Radiogram - Reynolds Universal
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Notes
-
Advertised as:-
REYNOLDS " MASTERPIECE" RADIOGRAM.
10-valve 3-wave superhet with an entirely new tone circuit. 12-inch speaker, 10 watts output. Musical reproduction is amazing. You must hear this!." It's unbelievable."—Symphony Orchestra Conductor.
PRICE 115 guineas. Plus Tax.
- Price in first year of sale
- 120.75 GBP
- Mentioned in
- Wireless World (The), London (WW, 79) (Oct 1947 Page Ad 55)
- Author
- Model page created by Clive Forder. See "Data change" for further contributors.
