Harris Scanner RF-536A
RF Communications, Inc.; Rochester, N.Y.
- Country
- United States of America (USA)
- Manufacturer / Brand
- RF Communications, Inc.; Rochester, N.Y.
- Year
- 1983
- Category
- Radio module post 1925 (not a part, not a key)
- Radiomuseum.org ID
- 296290
Picture from manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Powered by external power supply or a main unit.
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Harris Scanner RF-536A - RF Communications, Inc.;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 7.5 x 3.75 x 6 inch / 191 x 95 x 152 mm
- Notes
-
The RF-536A Scanner adds FSK and voice scanning capability to the RF-2330 Channelized ARQ System. Channels programmed into the RF-530A receiver are monitored during opeation for a one-second interval during each pass of the scanner. The presence of a valid FSK or voice stops scanner operation, and the active channel will be monitored until the signal is removed.
The RF-536A scanner is housed in the RF-236 power supply.
Dimensions are for the RF-536A only.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
