PLL Digital 12-Band World Receiver TRA-2425PSW

Roadstar; Japan

  • Year
  • 2015 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 285586
    • Brand: Roadstar El. GmbH

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Line / Batteries (any type) / 230 / UM3: 4 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
  • Power out
  • 0.1 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: PLL Digital 12-Band World Receiver TRA-2425PSW - Roadstar; Japan
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 218 x 107 x 60 mm / 8.6 x 4.2 x 2.4 inch
  • Notes
  • ROADSTAR - PLL Digital World Receiver 12-Band Reception SW (1-10) /MW/FM mod. TRA-2425PSW

    Radio portatile digitale multibanda hi-quality -  ricevitore FM / AM PLL a 12 bande (1 x FM, 1 x AM, 10 x OC) ad alta sensibilità e selettività. 24 preset ( 8 x FM, 8 x AM, 8 x OC).
    Sintonia automatica e con ricerca manuale. Lettura digitale della frequenza con grande display retroilluminato di colore blu. Orologio con sveglia/allarme e sleep function.
    Controllo elettronico di volume, altoparlante a larga banda e uscita cuffia. Colore nero. Consumo: 1,8 watt.

    10 SW bands:  3.16/3.45 MHz - 3.86/4.05 MHz - 4.71/5.10 MHz - 5.91/6.25 MHz
    7.01/7.40 MHz - 9.17/9.99 MHz - 11.51/12.15 MHz - 13.51/13.90 MHz
    15.01/15.70 MHz - 17.26/18.10 MHz.

    AM range: 552/1620 kHz - FM range: 87,5/108 MHz.

    Made in P.R.C. (China)

    Distributed for/in Europe by
    Roadstar Management S.A., Via Passegiata 7, CH-6883 Novazzano, Switzerland.

  • Net weight (2.2 lb = 1 kg)
  • 0.485 kg / 1 lb 1.1 oz (1.068 lb)
  • Author
  • Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
