PLL Synthesized World Band Receiver TRA-2350P

Roadstar; Japan

Data

Forum

Pictures

Collections

Country
Japan

Manufacturer / Brand
Roadstar; Japan

Year
2006 ?

Category
Broadcast Receiver - or past WW2 Tuner

Radiomuseum.org ID
305874

- Brand: Roadstar El. GmbH

Schematics

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2572981) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (3)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2572982) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (3)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2572983) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (3)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2572984) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (3)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2324494) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2324497) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2324353) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2324354) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2324360) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2324495) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2324499) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571187) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571188) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571189) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571190) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571191) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571192) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571193) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571194) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571195) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2571196) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2572985) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (2)
Service manual.

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2572986) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

PLL Synthesized World Band Receiver TRA-2350P; Roadstar; Japan (ID = 2572987) Radio — Roadstar; Japan PLL Synthesized World Band Receiver TRA-2350P (1)

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Transistors
Semiconductors present.

Semiconductors

Main principle
PLL, Phase-locked loop

Wave bands
Broadcast, more than 2 SW bands plus FM or UHF.

Power type and voltage
Line plus power jack, mostly with battery or storage battery / 230 or 6 or 4 x 1,5 Volt

Loudspeaker
Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12.7 cm = 5 inch

Power out
2.5 W (unknown quality)

Material
Plastics (no bakelite or catalin)

from Radiomuseum.org
Model: PLL Synthesized World Band Receiver TRA-2350P - Roadstar; Japan

Shape
Portable set > 8 inch (also usable without mains)

Dimensions (WHD)
290 x 185 x 70 mm / 11.4 x 7.3 x 2.8 inch

Notes
PLL Synthesized, Dual Conversion, 5-Band Receiver.

SW(1-3) / MW / FM-Stereo
High Sensitivity and Selectivity
AM RF Gain Control
Narrow / Wide AM Band with Selector
DX / Local AM Selector
Battery & Signal Strength Indicator
Large LCD Display with Illumination
Separate Bass & Treble Controls
Internal / External Antenna Selector
Clock/Alarm/Sleep/Timer Function
AC 230V / DC 6 V / Battery Operation
AM & FM External Antenna Input
Line & Earphones Output
Memory for 50 preset stations

Batteries: 4 x type D or 4 x AA alkaline batteries
Socket for 6 - 9 V DC PSU
AC 230 V 50 Hz, power cable supplied

Frequency ranges:

FM 87.00 - 108.00 MHz
MW 522 - 1620 kHz in 9 kHz-steps or 520 - 1710 kHz in 10 kHz steps
SW1 1711- 10010 kHz
SW2 9990- 19999 kHz
SW3 20000- 29999 kHz

FM 87,00 ~ 108,00 MHz
MG 522 - 1620 kHz 9 kHz-stappen of 520 - 1710 kHz 10 kHz-stappen
KG1 1711- 10010 kHz
KG2 9990- 19999 kHz
KG3 20000- 29999 kHz

Similar to Redsun RP-2100 model

Net weight (2.2 lb = 1 kg)
2 kg / 4 lb 6.5 oz (4.405 lb)

Price in first year of sale
22,000.00 HUF

Mentioned in
- - Manufacturers Literature (Specification on Roadstar website)

Author
Model page created by Pim Goddijn. See "Data change" for further contributors.
