Color-Vision RC-8138
Robotron-Elektronik Radeberg, VEB; Radeberg (Ostd:)
- Country
- Germany
- Manufacturer / Brand
- Robotron-Elektronik Radeberg, VEB; Radeberg (Ostd:)
- Year
- 1989
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 136226
Prospektbild
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- A38NCR00X05
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2.5 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Color-Vision RC-8138 - Robotron-Elektronik Radeberg,
- Shape
- Miscellaneous shapes - described under notes.
- Notes
- Der Color-Vision RC8138 entspricht in seiner elektrischen Konzeption dem RC9138, hat aber ein Gehäuse im Monitorlook. Das Gerät verfügt nur über eine Ortsbedienung und hat einen mechanischen Programmspeicher mit 8 Programmplätzen. Der Kabeltuner hat 99 Empfangskanäle, PAL und Secam nach CCIR.
- Literature/Schematics (1)
- Service-DVD Funkverlag B. Hein
- Author
- Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
