Prominent de Luxe 214; Robotron-Elektronik (ID = 2549140) Radio
Robotron-Elektronik: Prominent de Luxe 214 [Radio] ID = 2549140 1400x326
Select picture or schematic to display from thumbnails on the right and click for download.
For model Prominent de Luxe 214, Robotron-Elektronik Zella-Mehlis, VEB; Zella-Mehlis /Thür. (Ostd.)

Country:  Germany
Manufacturer / Brand:  Robotron-Elektronik Zella-Mehlis, VEB; Zella-Mehlis /Thür. (Ostd.)
Brand

Rechenelektr. Meining./ Zella
Year: 1975 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: ГТ313 ГТ322 ГТ322 ГТ322 ГТ322 SC207 SC206 AC187 AC188 B20C25 M25/10-0,36
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 5 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out 1.6 W (unknown quality)
from Radiomuseum.org Model: Prominent de Luxe 214 - Robotron-Elektronik Zella-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 680 x 150 x 150 mm / 26.8 x 5.9 x 5.9 inch
Notes Gerät aus der Prominent-de-luxe-200-Modellreihe, in Sonneberg entwickelt, etwa 1975 Produktion nach Robotron-Elektronik Zella-Mehlis verlagert. Exportausführung für OIRT (FM-Bereich).
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Source of data - - Data from my own collection
Literature/Schematics (1) Radio- es TV- kapcsolások, 1975-77

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
