Jukebox 1454

Jukebox 1454; Rock-Ola (ID = 1409732) R-Player

Jukebox 1454; Rock-Ola (ID = 1409733) R-Player
Jukebox 1454; Rock-Ola (ID = 1948562) R-Player Jukebox 1454; Rock-Ola (ID = 704843) R-Player
Jukebox 1454; Rock-Ola (ID = 2404126) R-Player
Use red slider bar for more.
Jukebox 1454; Rock-Ola (ID = 1948562) R-Player
Rock-Ola: Jukebox 1454 [R-Player] ID = 1948562 1288x2100
Select picture or schematic to display from thumbnails on the right and click for download.
For model Jukebox 1454, Rock-Ola Manufacturing Corporation (Rockola); Chicago, IL:
Gerät steht im Rundfunkmuseum der Stadt Fürth.

Country:  United States of America (USA)
Manufacturer / Brand:  Rock-Ola Manufacturing Corporation (Rockola); Chicago, IL
Year: 1956 Category: Sound/Video Recorder and/or Player
Valves / Tubes 6L6 6L6 6SN7 6SN7 5U4
Main principle Audio-Amplification
Wave bands - without
Details Jukebox-Coin operated Phonograph
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 38 cm = 15 inch
Power out
from Radiomuseum.org Model: Jukebox 1454 - Rock-Ola Manufacturing
Material Various materials
Shape Console, Lowboy (legs < 50 %).
Notes Jukebox mit 120 Wahlmöglichkeiten, also 60 Singles mit 45 rpm.
Literature/Schematics (1) Musikboxen v. Adams/ Lukas/ Maschke

Model page created by Nico Pokrant. See "Data change" for further contributors.



All listed radios etc. from Rock-Ola Manufacturing Corporation (Rockola); Chicago, IL
Here you find 58 models, 45 with images and 8 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
