11/6M Ch=663R1 Export Mantel Cabinet
Rogers (Brand), A R Harris Company Ltd.; Christchurch
- Country
- New Zealand-Aotearoa
- Manufacturer / Brand
- Rogers (Brand), A R Harris Company Ltd.; Christchurch
- Year
- 1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 339958
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 115 or 230 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: 11/6M Ch=663R1 [Export Mantel Cabinet] - Rogers Brand, A R Harris
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Dimensions (WHD)
- 415 x 530 x 305 mm / 16.3 x 20.9 x 12 inch
- Notes
-
6-Valve superhet with RF stage all wave table tombstone receiver.
Rogers 115 & 230v export version manufactured by Rogers-Majestic, Toronto, Canada.
Distributed in New Zealand by A R Harris Company Ltd.
See also Majestic 11/6C Ch= 663R1 Export.
- Mentioned in
- -- Collector info (Sammler)
- Literature/Schematics (1)
- -- Original prospect or advert (Timaru Herald 8 August 1936 Page 20)
- Literature/Schematics (2)
- The Golden Age of Radio in the Home 1986 (Page 129-133)
- Author
- Model page created by Brian Stevens. See "Data change" for further contributors.
