• Year
  • 1960 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 183468
    • alternative name: Rogers Radio Tube

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 452 kHz
  • Tuned circuits
  • 8 AM circuit(s)
  • Wave bands
  • Broadcast plus more than 2 Short Wave bands.
  • Power type and voltage
  • Dry Batteries / 6 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: All-Transistor RG-6059-T - Rogers-Majestic, Standard
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 12.25 x 8.5 x 4 inch / 311 x 216 x 102 mm
  • Notes
  • Manufactured by Philips using the Rogers Majestic brand. The same model is also available as Philips 4-L-05.
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Jose Casas-Avalos. See "Data change" for further contributors.
