Majestic 860 Ch= 8M623
Rogers-Majestic, Standard Radio Manufacturing, Rogers Radio Tubes; Toronto
- Country
- Canada
- Manufacturer / Brand
- Rogers-Majestic, Standard Radio Manufacturing, Rogers Radio Tubes; Toronto
- Year
- 1938/1939
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 159195
-
- alternative name: Rogers Radio Tube
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: Majestic 860 Ch= 8M623 - Rogers-Majestic, Standard
- Notes
- This set has preset push-button tuning. The Rogers 13-60 and De Forest Sousa are electronically identical to this set.
- Circuit diagram reference
- Radio College of Canada
- Mentioned in
- RCC Rogers-Majestic section page 42 & 44
- Author
- Model page created by Robin Roeckers. See "Data change" for further contributors.
