Rogers-Majestic,: Rogers 12-60 Ch= 7R621 [Radio] ID = 906124 800x616

Select picture or schematic to display from thumbnails on the right and click for download.

For model Rogers 12-60 Ch= 7R621, Rogers-Majestic, Standard Radio Manufacturing, Rogers Radio Tubes; Toronto:
By courtesy of guest Lew Magrish, USA and Steve Adams from radioattic.com.

Country:

Canada

Manufacturer / Brand:

Rogers-Majestic, Standard Radio Manufacturing, Rogers Radio Tubes; Toronto

alternative name

Rogers Radio Tube

Year: 1937/1938

Category: Broadcast Receiver - or past WW2 Tuner

Valves / Tubes

6: 6A7M 6K7M 75M 41M 2X3 2X3

Main principle	Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
Tuned circuits	6 AM circuit(s)
Wave bands	Broadcast and Short Wave (SW).
Details
Power type and voltage	Alternating Current supply (AC) / 115 Volt
Loudspeaker	Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org	Model: Rogers 12-60 Ch= 7R621 - Rogers-Majestic, Standard
Material	Wooden case
Shape	Tablemodel, low profile (big size).
Dimensions (WHD)	17.25 x 12.13 x 10.08 inch / 438 x 308 x 256 mm
Notes	The Rogers 12-60B, Majestic 760, 760B, De Forest Erie and Erie B are electronically identical.
Circuit diagram reference	Radio College of Canada
Mentioned in	RCC Rogers-Majestic section page 28 & Cross Reference
Literature/Schematics (1)	-- Original-techn. papers. (Rogers-Majestic & De Forest Service Manual Volume 3, page 9)

Model page created by Robin Roeckers. See "Data change" for further contributors.
