Rogers 15/78 Ch= 10R791
Rogers-Majestic, Standard Radio Manufacturing, Rogers Radio Tubes; Toronto
- Country
- Canada
- Manufacturer / Brand
- Rogers-Majestic, Standard Radio Manufacturing, Rogers Radio Tubes; Toronto
- Year
- 1940/1941 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 299719
-
- alternative name: Rogers Radio Tube
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 7
- Main principle
- Superhet with RF-stage; ZF/IF 456 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast plus more than 2 Short Wave bands.
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- from Radiomuseum.org
- Model: Rogers 15/78 Ch= 10R791 - Rogers-Majestic, Standard
- Notes
-
The Rogers model 15/78 is a 7-tube radio for broadcast and shortwave reception. Has tuning eye tube and internal loop antenna for the broadcast band. Same schematic and chassis as the Deforest "Calcutta" and the Majestic 41/78.
- Literature/Schematics (1)
- - - Manufacturers Literature (Rogers service manual Vol 3 P. 137)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
