FM/AM/SW Twin Speaker RE-1915-N (Japan 403 or 602 or 707) 13 Transistor

• Country
• United States of America (USA)

• Manufacturer / Brand
• Ross Electronics Corp.; Chicago (IL)

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 306791

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Short Wave plus FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 115 or C: 4 x 1.5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: FM/AM/SW Twin Speaker RE-1915-N [13 Transistor] - Ross Electronics Corp.;

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 9.5 x 6 x 3 inch / 241 x 152 x 76 mm

• Notes

• Made in Japan 403 or 602 or 707

• Author
• Model page created by Aldo Andreani. See "Data change" for further contributors.
